Kverneland Roc 1038
Rastrillos de cintas | Rastrillos de cintas para cultivos secos
Excelente rendimiento en entornos difíciles
Rastrillo de cinta suspendido de 1 pick-up con un ancho de trabajo de 3,8 m
Destacado
- Six bar pick-up and wide stripes provide the best performance in all types of crops
- The headstock can be equipped with an optional hydraulic suspension
- Standard wide suspended tandem wheels and emergency skids to protect the pickup
- Electric adjustable working height
- Even and fluffy swaths due to unique belt system
Descripción
El Kverneland Roc 1038 es una máquina ligera diseñada para regiones montañosas y terrenos difíciles. Puede montarse en la parte delantera o trasera del tractor y permite rastrillar sin pisar el cultivo. Ofrece una conducción cómoda con un ancho de transporte inferior a 3 m y retrovisores de serie. Los hileradores Kverneland tienen un diseño único de pick-up y cinta, que permite una recogida eficiente del cultivo y un flujo constante. También se puede utilizar para girar las hileras ya formadas. El flujo de aceite hidráulico del tractor permite que la cinta gire a la izquierda o a la derecha, y sus ruedas tándem de suspensión mecánica estándar garantizan un buen seguimiento del terreno. El cabezal se bloquea automáticamente cuando se levanta, lo que permite una fácil adaptación al terreno.
Destacado
- Rastrillo de cinta suspendido con 3,8 m de ancho de trabajo, adecuado para cultivos en seco.
- Diseñado para montarse delante o detrás de un tractor.
- Sistema de recogida único con 6 barras y diseño de correa para garantizar una rastrillado limpio.
- El sistema hidráulico estándar y los espejos garantizan un control completo de la máquina.
- Ruedas tándem.
- Sistema eléctrico de ajuste de altura de rastrillado.
- Fácil mantenimiento, calidad y sustitución de componentes.
Características
Características
- A single belt system
- Fibreglass-reinforced saw blade-shaped crossbars provide optimal transportation for dry and wet crops
- An actively-driven belt, equipped with a sprocket and gear belt, ensures continuous operation even in heavy crop conditions
- Most maintenance and repairs can be done without removing the belt, and all parts can be disassembled with a single wrench
- The speed of the belt and pick-up can be precisely adjusted
- The tension of the belt is evenly distributed between the left and right sides since it is adjusted centrally
- Controlled pick-up with two cams and six tine bars
- Transport even the shortest crops easily with hydraulic adjustable and suspended roller
- Heavy-duty plastic strippers are designed to maintain their shape even when they encounter rocks.
- The design of strippers is specifically made to prevent crop displacement caused by the tine
- Replacing tines with only two bolts to remove (one per tine and one per plastic stripper) using only one hand
- It is possible to repair bearings, cam track and tine bars without disassembling the pick-up
- Electric height adjustment
- Perfect solution for raking in front of the wheels (rear mounting is possible as well, for driving in reverse)
- Easy to enter corners and small fields
- Ideal combination with small squares or round balers
- Ideal for turning existing swaths like straw after the combine
- To ensure a high speed and a clean crop in all conditions, four suspensions are used
- The pickup's standard tandem wheels protect the ground from damage
- The tandem wheel comes equipped with a spring suspension system
- Our mergers are designed and built to be maintenance-friendly
- All components can be easily disassembled
- Wear parts are in small size and replaceable with limited efforts
Características técnicas
Características técnicas
Descargar catálogo| Kverneland Roc 1038 | ||
|---|---|---|
| Ancho de trabajo (m) | 3.8 | |
| Ancho de recogida (m) | 2.95 | |
| Ancho en circulación (m) | 3.0 | |
| Cintas | 1 | |
| Potencia necesaria (cv) | 60 | |
| Peso (kg) | 820 |
Características técnicas
Características técnicas
Descargar catálogoWorking width (m) |
Pick-up width (m) |
Transport width (m) |
Power requirement (hp) |
Weight (kg) |
|
Kverneland Roc 1038 |
3.8 |
2.95 |
3 |
60 |
820 |
